The introduction of the control system of the automatic rock slab cutting machine
time : 2021-04-26 11:03 views : 33

The control system of the automatic rock slab cutting machine mainly focuses on the forward and reverse rotation of the feed motor, the forward and reverse rotation of the lifting motor and the positioning of the spindle system. Let's briefly introduce it below.

Rock slab house setting

1.feed control system


The forward and reverse rotation and the feed speed of the feed motor are controlled by the inverter, which can realize the panel speed regulation. The feed position is controlled by the feed positioning and left and right limit proximity switches. There are two modes, automatic and manual.


2. lift control system


The lifting system realizes the set depth drop of the saw blade and the return of the initial position, which is controlled by the motor forward and reverse. There are two modes, automatic and manual.


3.spindle positioning system


The positioning system mainly realizes the forward distance positioning to ensure the accuracy of cutting materials. There are two modes, automatic and manual.

The control device of the automatic rock cutting machine adopts a microcomputer computer control system, and the power source is the main motor of each action unit, including feed, lifting and positioning motors, water pumps and saw blade motors. The control content includes the forward and reverse rotation of each action unit motor, sensor signal collection, and motor start-stop protection. The main objects of control and collection include sensor signals, motor start-stop relays, motor commutation relays, etc.

Automatic rock slab cutting machine.

Foshan Nanhai Hongyun Rock Slab Machinery Co., Ltd. is located in Baishaqiao Industrial Park, Shishan Town, Nanhai District,Foshan City, Guangdong Province,China. It is now mainly engaged in production: automatic rock slab cutting machine, rock slab 45-degree edge grinding machine, and special-shaped chamfering machine, Rock slab AC five-axis waterjet cutting machine, rock slab special-shaped edge grinding machine, rock slab double-head fillet polishing machine and other supporting production machinery for rock slab processing plants. It can process rock slab dining tables, round tables, horse-shaped edging, bathroom sinks, cabinets, coffee tables, TV background walls, etc. It is especially suitable for whole-house customization enterprises. The processing process will not produce breaks, corners, size heads, and different polishing brightness and the other problems.
