Model 1200 double group four blade CNC cutting machine is a new type of Multi Size cutting machine developed by Foshan Nanhai Hongyun Ceramic Machinery Co., Ltd. It is especially suitable for three sizes of rock slab bathroom table [panel + side plates on both sides] and conjoined stair step. This machine has two models of model 1200 and 1800, and can select different models for different plates. It is especially suitable for rock slab processing plant and ceramic tile processing plant.

                               Equipment parameters:

                               Cutting speed: 3-5M / min

                               Cutting width: 10-1200mm

                               Processing thickness: 6-30mm

                               Total power: 13.5KW

                              Water consumption: 100L / min

                               Equipment weight: 3000kg

                               Equipment size: 3300 mm * 2800 mm * 1700 mm

    Characteristics of hy-1200 CNC double group four blade cutting machine:

    1. High speed cutting: double group of four blades cutting three sizes at the same time, no dropping corner, good cutting effect and fast cutting speed.

    2. CNC double cutter head: it is composed of two CNC systems, one controls a cutting group, which can quickly set the two sizes to be cut, so as to achieve the purpose of fast positioning cutting.

    3. High power motor: 5.5kW motor, cutting more powerful.

    4. Double cutting head: it is composed of two cutting heads. The first one cuts half of tile, and the second one cuts off, so that there is no cracking.

    5. Accurate dual CNC system: with dual independent CNC system, the operation is convenient and accurate, and the cutting accuracy error is only 0.1mm.

    Foshan Nanhai Hongyun Ceramic Machinery Co., Ltd is a professional enterprise focusing on the field of ceramic tile deep processing equipment. It mainly manufactures arc polishing machine, full numerical control ceramic tile cutting machine, hand push numerical control ceramic tile cutting machine, ceramic tile cutting machine, arc line polishing machine, stone edge grinding machine, ceramic tile chamfering machine, mosaic slotting machine and other ceramic deep processing equipment. Our company is a one-stop enterprise,integrating producing, sales, installation, training, after-sales service , and really realize directly from the factory to the customer, without any dealer link, greatly saving the purchase cost for customers, welcome to visit our factory.
