Pos: Company > Porcelain Tile Cutting Machine > 1200 Automatic CNC Three-blade Cutting Machine
< >
  • 20210411150957_63890.jpg
  • 20210411150959_63075.png
  • 20210411151004_95280.png

The 1200 automatic CNC three-blade cutting machine is re-developed and upgraded based on the practical experience of ceramic processing plants in the past few years. The first blade: resin trimming, the second blade: cutting blade (cutting half), the third blade: cutting blade (cutting off). The new generation of CNC three-blade cutting machine adopts oil immersed screw rod, which greatly improves the accuracy and service life of the gauge by 2-3 times.


1.Product features:

(1)Batch cutting and repairing the broken ceramic tile surface can be finished at the same time ;

(2)The motor power of the double cutting spindle is upgraded to 4KW, and the cutting speed can be 35% higher than that of the traditional CNC cutting machine ;

(3)The machine is easy to operate and has a high degree of automation , you can quickly set the guiding rule just by setting the required cutting size on the operation plane ;

(4) All cutter heads are upgraded to electric lifting cutter heads.


2. Technical parameters:


Conveyor belt width

800mm

Cutting speed

3-5m/min

Diameter of cutting blade



120-150mm

Cutting shaft power

4.0KW

Machinable width

10-1200mm



Machinable thickness

6-20mm

Water consumption

150L/min



Total power

13KW

Weight

1600Kg

Size



2600*2000*1800mm


3. Equipment display:

The 1200 Automatic CNC Three-blade Cutting Machine.

4.The cutting effect:

The Cutting Effect of Automatic CNC Three-blade Cutting Machine
