Recently, a friend asked how to install the tile cutter? What are the precautions when using? When buying a ceramic tile cutter, there are usually professionals to guide the installation, use, and maintenance. Let me share with you the installation method of the tile cutter.

Tile cutter installation skills

　　 1. Place two parallel tracks on the ground first. Its width is the same as the width of the walking wheel of the cutting frame.

　　2. Put the rack on the parallel track, and move it back and forth completely to the track and move freely.

       3. Put the main frame of the stone cutter on the frame. The four rollers on the main frame should be completely consistent with the channel steel on the frame, and the direction of movement of the main frame after being placed crosses the direction of the frame at 90 degrees and each Move freely.

　　4. Install the power so that the motor is firmly connected to the host through the motor tripod, and the axis of the motor crosses the direction of the host horizontally and vertically.

　　 5. Install the belt.

　　 6. Install the guard.

　　7. Start the motor and check that the rotation direction of the saw blade shaft is consistent with the direction indicated by the arrow of the guard.

　　 8. Install the saw blade. Connect the water pipe.

Tile cutter cutting precautions:

　　 1. In the cutting process, you must pay attention to the position of the saw blade and control the speed of the cutting product, and take self-protection measures to prevent being cut.

　　2. During the cutting process, the debris of the product must be cleaned with water, and it is strictly forbidden to clean it by hand.

　　3. When cutting, the distance between the hand and the cutting piece should be kept above 10 mm to prevent the cutting piece from hurting the hand.

　　4. Use different types of saw blades to cut different types of tiles.

　　 The above is the entire content of the installation guide for the tile cutter shared by ours. If you want to know more related information, you can consult the online customer service of Foshan Nanhai Hongyun Ceramic Machinery Co., Ltd., or go to the company for on-site inspection.
