The common problems in ceramic tile machine are: the surface of ceramic tile is uneven, the conveyor belt is deviated, the idling processing, the motor is connected or stopped, and the product error is large, so how to solve these problems in the process of processing ceramic tile?

1. the surface of tile is not flat

The main reason for the uneven surface of the ceramic tile is that the pressure of the roller is not uniform, which leads to the gap between the roller and the ceramic tile surface. The roller should be checked for damage and then readjusted to make the roller stick to the tile surface.

2. Belt deviation

The conveyor belt on the transmission shaft of ceramic tile processing machine runs out of the way, and there are two rectifying wheels under the belt. If the conveyor belt deviates from the side of the electric control cabinet, loosen the fixing nuts near the electric control cabinet, move the adjustment roller up and tighten the screw. If it run to the other side, move up the roller on the other side.

3. The idling processing

When using ceramic tile processing machine, the speed of frequency conversion motor cannot be too fast, too fast will cause the belt speed and tile processing speed inconsistent, resulting in negligence in processing, motor idling without tile passing, or tile running too fast without finishing processing. The speed of the inverter motor shall be adjusted and adjusted according to the data given by the manufacturer.

4. Motor is connected or stopped or misoperated

Check whether the circuit and electrical adjustment parameters are appropriate, and whether the connectors between the electrical rooms are loose, etc. Check whether the battery brake is in normal working condition and whether the proximity switch is working.

5. large product error

There is a lack of edge on the surface of the conveyor belt. The vertical line of the conveyor belt shall be adjusted to keep parallel to ensure the width of the belt is consistent, so as to ensure no missing edge.

The above is the common problems and solutions of ceramic tile processing machinery. There are many problems in the process of ceramic tile processing machinery. These problems need to be found and solved by operators carefully. For the more difficult problems, we can discuss with the equipment manufacturers.
