The porcelain tile special-shaped edge grinding machine is mainly used for the special-shaped edge grinding of the porcelain tile table/coffee table/cabinet, etc. The machine can grind the round edges, chamfer and polish, and it can also do internal grinding. Among them, the round table can be automatically ground. For special-shaped surfaces, it works by hand pushing semi-automatically.It is a multi-functions equipment with high cost performance, and is one of the indispensable equipment for porcelain tile processing plant.
1. Technical parameters:
Working size
| 100-2100mm | Grinding Thickness | 3-30mm |
Bevel angle | 0-20
| Rotary speed | 1-4 circles/min |
Satellite turntable speed | 2-10 circles/min | Bevel edge grinding wheel | ф150 (bowl-shape) |
Edging wheel | ф100ф150 (preferred) | Voltage 3-phase | 380V/50HZ
|
Beveled edge grinding diameter
| 400-2100mm | Maximum bevel width | 35mm |
Total power
| 3.2kw | Weight | 1000kg |
Size
| 1200*1200*1800mm | ||
2. Equipment display:
3.The processing effect:
