The porcelain tile round table cutting and grinding all-in-ones is specially designed for processing porcelain tile round table. The machine can complete cutting, edge grinding and smooth out at once, and does not need to move back and forth. It has high production efficiency. The cutting size is precisely adjusted by CNC control system and air pressure for edge grinding, chamfering and polishing. Taking 800mm round table as an example, the completion time of cutting,edge grinding and polishing is about 4-5 minutes.


1. Technical Parameters:


Working table size

800*1600mm

Cutting speed

1.5-2laps / min

Edging and chamfering speed



2-3 laps / min

Diameter of cutting blade

130mm

Grinding and polishing wheel number

3

Processing thickness

6-20mm

Water consumption



150L/min

Total power

12KW

Weight



1500KG

Size

3500*2000*1700mm


3. equipment display:

Rock Slab Round Table Cutting And Grinding All-in-ones Machine

3.The processing effect:

Rock slab round table1

Rock slab round table2

Rock slab round table3
