The 1800 CNC three-blade cutting machine is mainly designed for cutting large-size  porcelain slabs and ceramic tiles. It is one of the indispensable equipment for porcelain/ceramic tile deep processing plants.


1.Product features:

(1)batch cutting and edge trimming can be finished in one operation without cracking or dropping the corners;

(2)The maximum cutting size : 1.8 meters , speed : 3-5 m/min , and it is suitable for cutting large-size porcelain tile in porcelain tile processing plant , with high precision and good cutting effect;

(3) One CNC three-blade cutting machine can replace five manual cutting machines , the processing cost is extremely low, the cutting effect is stable , and no cracking or dropping corners.



2. Technical parameters:


Conveyor belt width

1000mm

Cutting speed



3-5m/min

Diameter of blade



120-150mm

Cutting shaft power

4.0KW

Machinable width

10-1800mm

(one side10-900mm)

Machinable thickness

6-20mm

Water consumption

150L/min



Total power

13KW

Weight

1800Kg

Size



2800*2600*1800mm


3. Equipment display:

1800 CNC Three-blade Rock Slab  Cutting Machine

4.The cutting effect :

The cutting effect of the 1800 CNC three-blade rock slab cutting machine

The cutting effect of the 1800 CNC three-blade rock slab cutting machine
